Specifications

  • L.O.A. 42’ 10” (13.06 m)
  • Beam 13' 0" (3.96 m)
  • Hull Draft  (motors up)2’ 4” (0.71 m) (motors down)3’ 11” (1.19 m)
  • *Clearance w/Hardtop  (from waterline)9’ 3” (2.81m)
  • Approx. Dry Weight  (triple F350 engines)20,777 lbs. (9,424 kg)
  • **Fuel Capacity 470 U.S. gallons (1,779 L)
  • Diesel Generator Tank23 U.S. gallons (87 L)
  • Fresh water Capacity 46 U.S. gallons (174 L)
  • Holding Tank Capacity 22 U.S. gallons (83 L)
  • Livewell Capacity 42 U.S. gallons (159 L)
  • Fishbox Capacity 50 U.S. gallons (189 L)
  • Max. Horsepower 1275 hp (951 kw)
  • Deadrise 20°


*Hardtop Clearance shown does not include options which could increase this height dimension.
**Net tank capacity. The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.


Performance Reports
Triple Yamaha® F350 Engines
Triple Yamaha® F350 Engines with Tower

S 408 Product Brochure - View Online
Full Line Product Catalog - View Online









The S 408 beckons big-game fishermen and families alike with a true center console footprint and the luxury amenities of Pursuit’s Sport Series.

A stout helm, rugged hardtop, large cabin space and tremendous seating choices around the cockpit mark the S 408 a leader in her category.

Pick your pleasure aboard the S 408, lounge, entertain, fish and dive all in the comfort of uniquely engineered social zones. The bow features a full sunpad along with lounge seating complimented by a convertible table. For the Captain a three-wide helm arrangement offers plenty of room and adjustment to enjoy operating the boat with friends and family are close by. Aft in the cockpit, complete with mezzanine seating, you can fish hard and entertain when dockside with amenities like the transom freezer box and electric grill. And with the privacy of an enclosed head and light kitchen amenities overnight for a short weekend getaway.


Gallery

Standard Equipment

Effective date: August 1, 2018

HULL Features

  • Pursuit® Protection Plan:
    5-year hull/deck structural warranty
    5-year blister-free warranty
    2-year limited warranty
  • Pursuit Fresh White Gelcoat
  • Yamaha® white paint on engines
  • Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics
  • 5 Ply Resin Infused Composite Transom System with Patented Transom Reinforcement Grid
  • Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System
  • Foam Filled Structural Grid
  • Bronze Thru Hull Fittings Below Water Line
  • Chrome over Bronze Thru Hull Fittings Below the 7 Degree Heel Line
  • Stainless Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line
  • Bronze Garboard Drain
  • Trim Tabs, Lenco Electric with Auto-Retract
  • Integrated Transom Platform Extensions Outboard of Engines
  • Boarding Ladder, 4-Step Telescopic, Mounted in Hull Platform
  • Anchor System, Integrally Molded Thru-Stem
  • Bow Thruster, 5.4 HP (4.0 kW) with Group 31 AGM Battery, Switch and Fuse

DECK FEATURES

  • Hull and Deck Joint: Mechanically Fastened and Includes Aluminum Backing Plates At Cleat Locations
  • Rub Rail: High Density PVC with Solid 316L Stainless Steel Insert
  • Molded One Piece Deck and Cockpit Liner with Non-Skid Pattern Area
  • Flush Mounted Integral Anchor Locker with Fiberglass Lid including: Horizontal Anchor Windlass with Switch at Helm and Remote at Anchor Locker 316L Stainless Steel through Stem Anchor Roller with 8" Mooring Cleat and Chain Binder 35lb Stainless Steel Plow Style Anchor, Self-Righting Shackle, 300' Rode (5/8" 8 Plait including 15' of 5/16" G4 Chain) with Fresh and Raw Water Washdown in Anchor Locker
  • Flush Mounted Integral Anchor Locker with Fiberglass Lid
  • Cleats, 316 Stainless Steel, 10" Pop Up (2) Stern, (4) Spring and (2) Bow
  • Molded Recessed Hatches with Gaskets and 316L Stainless Steel Latches and Overboard Drain Tracks
  • Molded Transom Walkthrough with Hinged Transom Door, 316L Stainless Steel Latch and Magnetic Catch
  • Self-Draining Cockpit with Integrated Scupper Drains and Stainless Steel Drain Covers
  • Bow Grab Rails, 316L Stainless Steel (port & starboard)
  • Transom Grab Rails, 316L Stainless Steel (port & starboard)
  • Molded Non-Skid Steps in Splashwell for Athwartship Access
  • Navigation Lights, LED, 2 mile

COCKPIT FEATURES

  • Thirteen (13) Drink holders
  • Single Windshield Wiper with Fresh Water Washer
  • Raw Water Wash Down System: Pump with Bronze Thru-Hull, Ball Valve, and Strainer, Cockpit and Anchor Locker Outlets, Coiled Hose and Sprayer
  • Centerline Fiberglass Mechanical Space Hatch, Stainless Steel Gas Shock
  • Smoked Acrylic Sliding Companionway Door with Lock and Keeper, Sliding Screen
  • Pursuit Custom Triple Captain's Seats with Folding Armrests, 3 Sculpted Flip-Up Bolsters and Lumbar Support, Color Matched Acrylic Backrest
  • Helm Seat Box Content, Frig 2.3 cub ft with Pull-out Drawer (Isotherm) (Starboard side), Tackle Storage Drawer System (port side), DC Panel & Battery Switch Access Under Helm Seat, Storage Compartment (trunk) Under Aft Facing Mezzanine Seat
  • Aft Facing Mezzanine Seat with Teak Footrest
  • Hot & Cold Fresh Water Cockpit Shower
  • Bow Seating, Port and Starboard, with fold-up backrest to provide forward facing seating, Clear Passage Forward (Removable Jumpseat)
  • Storage Under Bow Seating Area Port and Starboard
  • Table with removable base for dining, designated storage position under removable jump seat
  • Storage Under Floor in Bow Area
  • Bow Sunpad Chaise with Fold-Down Armrests and Drink Holders
  • Storage Under Bow Sunpad with Consideration for Common Boating Equipment
  • Full Cockpit Breathable Coaming Bolsters with Dri-Fast Foam and Mesh Backing
  • Inward Opening Side Boarding Door Starboard Side with Removable/Storable Ladder for Water Play
  • LED Cockpit Courtesy Lights
  • Cockpit Fire Extinguisher
  • Dockside Fresh Water Inlet with Pressure Regulator
  • Instrument Cover (white Weathermax®)
  • Aft Mezz Seat Cover (white Weathermax®)
  • Helm Seat Cover (white Weathermax®)
  • Forward Bow Seating Cover (white Weathermax®)
  • Forward Sunpad Cover (white Weathermax®)

FISH FEATURES

  • Rod Holders (8), Stainless Steel, in Gunwale
  • Lighted Oceana Blue 44 Gallon Recirculating Insulated Livewell with Fiberglass Lid and Acrylic Window, Bottom Drain Plug, Bronze Thru-Hull, Ball Valve and Strainer
  • Under Gunwale Rod Storage (port)
  • Fish Boxes, in-deck (2 x 61 Gallon) Insulated, Diaphragm Pumps with Overboard Discharge (port & starboard)
  • Aluminum Reinforcement Plates and Wiring for Downrigger Installation, Port and Starboard
  • Aft Cockpit Prep Center, Fiberglass Lids (2), Fish Box (47 Gallon) Insulated with Refrigerator/Freezer Coils and Digitally Controlled Thermostat in Cabin, Sink with Pressurized Folding Hot/Cold Faucet, Corian® Cutting Board, 240V/60 Cycle Electric Grill and Tackle Storage Drawers (4)
  • Lockable Storage for Six (6) Rods under Bow Seating

HARDTOP & WINDSHIELD

  • Custom Integrated Fiberglass Framed Windshield with Laminated Glass with Electrically Actuated and Gasketed Passive Ventilation System
  • Fiberglass Hardtop with Dedicated Radar, Antenna and Outrigger Locations
  • White Hardtop Supports with Four (4) Rod Holders, with Integrated Ladder Rungs for Access to Hardtop
  • Custom Stainless Steel Ratcheting Anchor/Stern Light with Burgee Rings
  • Horn, Electric, Twin Trumpet
  • Two (2) Aft Facing Spreader Lights, One (1) Forward Facing Spreader Light
  • Five (5) Overhead Tri-Color Courtesy Lights
  • Integrated Stereo Speakers (4)

CABIN

  • Full Fiberglass Cabin Deck Liner with Sound Dampening Insulation
  • Full Fiberglass Hull Liner with Sound Dampening Insulation
  • Khaya and Wenge Veneer Accents
  • Cabin Entry Steps with Custom Handrail and Wood Treads
  • Custom Solid Wood Tongue and Groove Floor Accents, Mechanical Access and Drainage
  • 316L Stainless Steel Opening Port Lights (3) with Screens
  • Skylight Aft of Windshield to Provide Natural Light to Salon and Head
  • 230V/60 Cycle Cabin Air Conditioning with Reverse Cycle Heat, 8,000 BTU Self-Contained System
  • One (1) 110 Volt Outlet, GFI Protected
  • TV Antenna
  • JL Audio Stereo Speakers (2)
  • Refrigerator: 2.6 cu. ft. Vitrifrigo DW70
  • Microwave: 110-volt, 1.1 cu. ft.
  • Companionway 3-Switch Panel: (5) Accent Floor Lights and Galley Accent Lighting, (3) Overhead LED at Companionway, (2) Overhead LED Galley Lights
  • 28” Flat Screen TV
  • Forward Seating Area Converts to V-Berth with 4” Foam Cushions and Storage Beneath
  • Fire Extinguisher
  • CO Monitor

HEAD

  • Corian Countertops and Accents
  • Fiberglass Head
  • Head 2-Switch Panel: (2) Overhead Light (1) Floor Accent Light
  • Vacuum Flush Marine Head with 22 Gallon Holding Tank, Macerator Discharge Pump, Stainless Steel Deck Pump-out Fitting and Bronze Thru Hull Fitting with Seacock
  • Sink with Pressurized Hot/Cold Faucet
  • Vanity Storage Cabinet
  • 316L Stainless Steel Opening Port Light with Screen
  • 120V Outlet with GFI Protection (1)
  • 18” Towel Bar
  • Shower with Hot/Cold Mixing Valve
  • Shower Sump Box with Automatic Discharge Pump
  • Head Mirror(s)
  • Shower Curtain

HELM

  • Molded Fiberglass Aft Tilting Helm with Instrumentation Visor, Electronics Mounting Surface, Fold Out Fiberglass Footrest/Platform and Safety Lanyard
  • Molded Acrylic Access Door with Secondary Framed Screen Door and 316L Stainless Steel Locking Latch
  • 316L Stainless Steel Steering Wheel with Control Knob and Non-Slip Grip on Sport Tilt Plus Helm
  • 12V Panel with Illuminated Carling® Rocker Switches
  • Single Windshield Wiper with Washer Control
  • Compass
  • Trim Tab Control Panel and Indicator
  • Bow Thruster Joy Stick Control
  • Double-wide (Center & Starboard) FRP Fold-down Footrest with Nonskid Pattern
  • Top Load Glovebox, Starboard Side (contains dual USB charging ports)
  • 316L Stainless Steel Helm Drink Holders (2)
  • Helm Fire Extinguisher
  • Garmin Electronics Package: (2) 16” Multi-Touch Wide Screen Chartplotter Displays, Sonar, 4kW 48” Open Array Radar, Autopilot with SmartPump, Integrated VHF with Full-Function Handset and Remote Speaker, VHF Antenna
  • Yamaha® Command Link Plus Display
  • Dash/Instrument Cover

ELECTRICAL SYSTEMS

  • UL® Rated Fully Tinned, Color Coded Copper Wire
  • Custom In-House Built, Heat Sealed, Mechanically Crimped, Color Coded Battery Cables
  • Custom In-House Built, Electrical Harness with Water Proof Connectors and Chafe Protection
  • Powder Coated, Aluminum, Screen Printed (Front and Back) Battery Switch and Breaker Panel
  • Bonding System: Thru Hull Fittings Below Water Line, Trim Tabs, Zinc Anode and Garboard Drain
  • Seven Battery System: Port Engine (1), Starboard Engine (1), Center Engine/Generator (1), House (2) (AGM), Electronics (1) (AGM) and Bow Thruster (1) (AGM)
  • Single 240V 50 Amp 60 Cycle Dockside Power with Glendenning Cable Reel
  • Isolation Transformer
  • One (1) 40 Amp Battery Charger for Bow Thruster, House Bank and Electronics Batteries
  • One (1) 20 Amp Battery Charger for Engine and Generator Batteries
  • Pursuit Custom 12V and 120V Interior MDP Switch Panel for Cabin Interior Circuits
  • 12V and 120V Custom Master Circuit Breaker Switch Panel
  • One (1) 12 Volt Accessory Plugs in Cabin (Dual USB charging port)

MECHANICAL SYSTEM

  • Molded Interior White Gel Coat
  • Molded Hatch with Gasket and Stainless Steel Gas Spring
  • Teleflex Power Steering Pump
  • One 1500 GPH Bilge Pump with Electronic Switch, One 1500 GPH Bilge Pump with High Water Electronic Switch and Alarm with Stainless Steel Clad Composite Thru Hull Fittings
  • Fresh Water Pump with Filter
  • Raw Water Pump with Bronze Sea Strainer, Sea Cock and Thru Hull Fitting
  • Dedicated Fishbox Diaphragm Evacuation Pumps
  • Teleflex Power Steering Pump

FUEL SYSTEM

  • EPA Compliant Lined 159 Gallon (port & stbd), 153 Gallon (center) Rotomolded Fuel Tanks with Triple Engine Pickups, Shutoff Valves, Digital Level Indicator, Fuel Management Valve Manifold and Deck Fuel Fill Plates
  • Custom Built Premium Fuel Feed Lines with Mechanically Crimped Fittings
  • Three (3) Yamaha® Water Separating Fuel Filters with Primer Bulbs

WATER SYSTEM

  • 60 Gallon Water Tank with Level Indicator and 316L Stainless Steel Deck Fill Plate
  • Premium Sea Tech Color Coded Water Hose System with Mechanically Crimped Ends
  • Pressure Sensing/Variable Speed Pump
  • Fresh Water Distribution Manifold with Dedicated Valves
  • Dockside Fresh Water Inlet with Pressure Regulator
  • 6 Gallon Stainless Steel Water Heater, 240V/60 Cycle
  • Cockpit Shower with Hot/Cold Mixing Valve

GENERATOR

  • 240V/60 Cycle 8.0 kW Fischer Panda® Diesel Generator with Sound Shield and Service Slide
  • EPA Compliant Lined 25 Gallon Rotomolded Fuel Tank with Engine Pickup, Shutoff Valves, Digital Level Indicator, Water Separating Fuel Filter and 316L Stainless Steel Deck Fill Plate
  • Fire Suppression System

Pursuit reserves the right to change boat specifications, equipment, color schemes, and pricing, and/or discontinue models at any time without notice or obligation.
Some of the boats shown include optional or dealer-installed equipment.





Optional Equipment

BOAT w/ENGINES:

  • Triple Yamaha® Digital F425 (Pearlescent White)
  • Yamaha® Helm Master™ Steering System w/Set Point (F425s)
  • Yamaha® Helm Master™ Steering System Upper Station with F425 engines (must order lower station also)

COLOR SELECTIONS

  • Hull Color
    • Fresh White
    • Titanium
    • Neptune Gray
    • Pursuit Flag Blue
    • Gulf Stream Blue
    • Solid
    • Effect
  • Helm Color
    • Carbon - Standard
    • Titanium
    • Neptune Gray
    • Pursuit Flag Blue
    • Gulf Stream Blue
  • Boot Stripe Color
    • Black/Black - Standard
    • Navy/Navy
    • Platinum/Platinum
    • Red/Red
    • Scarlet/Scarlet
    • Arctic White/Quartz Gray
    • Custom

MECHANICAL SYSTEMS

  • Seakeeper 6 Gyro. Raw Water Cooled
  • Cockpit A/C 16,000 BTU
  • LED Spotlight w/Remote Control at Helm
  • All Color Sea Blaze X2 Spectrum Underwater Lights (4)
  • Bow Tender Tow Eye

COMFORT & CONVENIENCE

  • Refrigerator/Freezer Coils with Digitally Controlled Thermostat for Starboard Cockpit Fish Box
  • Icemaker in Helm Seat Box in lieu of Tackle Storage Drawer System
  • Aft Cockpit Table and table mount in cabin w/Cabin Receiver Storage
  • Helm Area Teak Flooring

UNDERSIDE HARDTOP COLOR

  • Gel Color - Titanium, Neptune Gray, Flag Blue, or Gulf Stream Blue
  • Paint Color - Titanium, Neptune Gray, Flag Blue, or Gulf Stream Blue

WEATHER GROUP

  • 3-Sided Enclosure w/Strataglass - Staimod® (White)
  • 3-Sided Enclosure w/Makrolon - Staimod® (White)
  • Wide-Winged Enclosure Stamoid®
  • Mediterranean Sunshade Forward
  • Engine cover (triple) - Sunbrella®
  • Sunbrella® Canvas color - Black, Tweed, Cadet Gray, or Navy

SPORT FISHING

  • Tower Land Delivery: (Pursuit employee will assist with installation)
    Tricolor overhead lighting, Compass, Yamaha controls, Tilt Steering, Trim Tab Control, Ignition switches with safety shutoffs, Bow thruster control, Helm Master Joystick (if selected), Yamaha display, Drink Holders (2 or 3), Speakers (2), Navigation Display (10” or 12”), VHF, Autopilot GHC20, Spotlight (if selected), Stereo remote (controlled through display), Glovebox, 12V outlet and USB outlet, Seating (for 2 or 3)
  • Hardtop Rocket Launchers (8)
  • Transom Rod Holders (5)
  • Taco Grand Slam 380 Outriggers w/18' Telescoping Poles
  • Rupp Tournament Outriggers (with tower option only)
  • Center Rigger (with tower option only)
  • Bow Rod Holders

ELECTRONICS

  • Sirius Satellite Radio with Hardtop-Mounted Antenna
