S 288
S 288



The Sport family provides stunning exterior profile with industry leading features.

Years of intense planning go into the release of new Pursuit models, and the S 288 is no exception. With its compact design, we’ve honed in on the essentials – but we’ll never lose our attention to detail. We’re ensuring it has everything you need and nothing you don’t.



GALLERY
SPECIFICATIONS



L.O.A.
30’ 0” (9.14 m)
Beam
9' 8" (2.95 m)
Hull Draft
(motors up)
(motors down)

2’ 0” (0.61 m)
3’ 0” (0.91 m)
*Clearance w/Hardtop
(from waterline)

7’ 9” (2.36 m)
Approx. Dry Weight
(twin F300 engines)

8,220 lbs. (3,729 kg)
**Fuel Capacity
230 U.S. gallons (871 L)
Fresh water Capacity
26 U.S. gallons (98 L)
Holding Tank Capacity
9 U.S. gallons (34 L)
Max. Horsepower
600 hp (447 kw)
Deadrise
24°





Plan View



*Hardtop Clearance shown does not include options which could increase this height dimension. **Net tank capacity. The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.





STANDARDS



Effective date: August 1, 2018

HULL FEATURES

  • Pursuit® Protection Plan:
    5-year Hull/Deck Structural Warranty
    5-year Blister-free Warranty
    2-year Limited Warranty
  • Pursuit® Fresh White Gelcoat
  • Yamaha® Paint on Engines
  • Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics
  • 5 Ply Resin Infused Composite Transom System with Patented Transom Reinforcement Grid
  • Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System
  • Foam Filled Structural Grid
  • Bronze Thru Hull Fittings Below Water Line
  • Chrome over Bronze Thru Hull Fittings Below the 7 Degree Heel Line
  • Stainless Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line
  • Bronze Garboard Drain
  • Trim Tabs, Lenco Electric with Auto-Retract
  • Bow Eye, 5/8" 316L Stainless Steel
  • Stern Eyes (2), 5/8" 316L Stainless Steel
  • Integrated Transom Platform Extensions Outboard of Engines
  • Boarding Ladder, 3-Step Telescopic, Mounted in Hull Platform
  • Anchor System, Integrally Molded Thru-Stem
  • Horn, Electric, with Oval Stainless Steel Cover
  • Dedicated Transducer Location
  • Horn, Electric, with Oval Stainless Steel Cover

DECK FEATURES

  • Hull and Deck Joint Mechanically Fastened
  • Rub Rail: High Density PVC with Solid 316L Stainless Steel Insert
  • Molded One Piece Deck and Cockpit Liner with Non-Skid Pattern Area
  • Flush Mounted Integral Anchor Locker with Fiberglass Lid including: Horizontal Anchor Windlass with Switch at Helm, Remote at Anchor Locker and Raw Water Washdown
  • 316L Stainless Steel through Stem Anchor Roller with 8" Mooring Cleat, Chain Binder, 14lb Stainless Steel Plow Style Anchor, Self-Righting Shackle and 200' Rode (1/2" 8 Plait including 10' of ¼" G4 Chain)
  • LED Anchor Locker Light
  • Cleats, 316 Stainless Steel, 8" Pop Up (2) Stern, (2) Spring and (2) Bow
  • Molded Recessed Hatches with Gaskets and 316L Stainless Steel Latches and Overboard Drain Tracks
  • Molded Transom Walkthrough with Hinged Transom Door, 316L Stainless Steel Latch and Magnetic Catch
  • Self-Draining Cockpit with Bronze Ball Valve at Hull Side
  • Bow Grab Rails, 316L Stainless Steel (port & starboard)
  • Transom Grab Rails, 316L Stainless Steel, (port & starboard)
  • Molded Non-Skid Transom Bridge for Athwartship Access
  • Navigation Lights, LED, 2 mile

COCKPIT FEATURES

  • Molded FRP Hull Side Boarding Door
  • Drink Holders (2), Located in Gunwale
  • Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing
  • Helm Seating with Teak Accents, Split Bolster, Foldable Armrests and Fore/Aft Adjustment
  • Molded Helm Seat Console with Drink Holders (2), Dedicated Tackle Storage, Storage Drawers, 12V MDP and Folding Aft Facing Seat
  • Pursuit Cockpit JL Audio Entertainment System: 12V Bluetooth® Compatible Stereo System, Premium Speakers (5 Total, 2 in Hardtop, 2 in Bow, and Subwoofer) and Amplifier
  • Folding Transom Seat with Adjusting Backrest
  • Aft Cockpit Machinery Access Hatch
  • Forward Cockpit Machinery Access Hatch
  • Fresh Water Wash with Chrome over Brass Pull out Sprayer and Quick Fittings
  • Raw Water Outlet in Cockpit with Quick Connect Fittings and 25' Hose
  • LED Cockpit Accent Lights (7) with Water Proof Switch in Cockpit
  • Forward Facing Seat for two on Front of Console with Armrests
  • Molded Forward Bow Seating with Insulated Storage Below, Removable Cushions, Folding Forward Facing Backrests for Port and Starboard Seats
  • Bow Tonneau Cover, Sunbrella®
  • Helm Companion Seat Cover, Sunbrella®
  • Fire Extinguisher (under starboard gunwale)

FISHING FEATURES

  • Rod Holders (4), Stainless Steel, in Gunwale
  • Lighted Oceana Blue 24 Gallon Recirculating Livewell with Acrylic Lid
  • Under Gunwale Rod Storage with Reel Pads (port & starboard)
  • Fish Boxes (45 gallons), Insulated and Diaphragm Pumps with Overboard Discharge (port & starboard)
  • Vertical Rod Holders (4), Stainless Steel, in Transom
  • Rod Storage Under Hardtop (port & starboard)

HARDTOP & WINDSHIELD

  • Molded Fiberglass Full Beam Hardtop
  • Custom Powder Coated Aft Structural Hardtop Supports
  • Custom Windshield System with Tempered Glass and Windshield Wiper
  • Custom Powder Coated Grab Rails on Windshield Frame (port & starboard)
  • Custom Stainless Steel Ratcheting LED Anchor/Stern Light with Burgee Rings
  • Four (4) Tri Color LED Lights
  • Fore and Aft Facing Spreader Lights
  • Integrated Stereo Speakers (2)
  • Hardtop Acrylic Access/Ventilation Hatch
  • Fiberglass Hardtop with Dedicated Radar, Antenna, Outrigger and Spotlight Locations

HELM

  • Molded Fiberglass Aft Tilting Helm with Instrumentation Visor, Electronics Mounting Surface, Fixed Fiberglass Footrest and Safety Lanyard
  • 316L Stainless Steel Steering Wheel with Control Knob and Non-Slip Grip on Sport Tilt Plus Helm
  • 12V Panel with Illuminated Carling® Rocker Switches
  • Single Windshield Wiper with Washer Control
  • Compass
  • Trim Tab Control Panel and Indicator
  • Waterproof Stereo Remote with Full Function Display
  • Integrated Glovebox with One 12V Outlet (1) and Dual USB Charger
  • 316L Stainless Steel Helm Drink Holders (2)
  • Fire Extinguisher (under port gunwale)
  • Yamaha® Command Link Plus Display
  • Dash/Instrument Cover

CONSOLE & HEAD

  • Two Piece Fiberglass Head Door with Gasket and 316L Stainless Steel Locking Latch
  • Molded Cabin Liner with Integrated Entry Steps
  • Vacuum Flush Marine Head with 9 Gallon Holding Tank, Macerator Discharge Pump, 316L Stainless Steel Deck Pump-out Fitting and Bronze Thru Hull Fitting with Seacock
  • Fiberglass Toilet Seat Cover
  • Designer Sink with Corian® Countertop, Fresh Water Faucet and Vanity Mirror
  • Integrally Switched 12V Overhead Light
  • 316L Stainless Steel Opening Port Light (1) with Screen
  • Storage Hooks (3)
  • Fire Extinguisher
  • Toilet Tissue Holder

ELECTRICAL SYSTEMS

  • UL® Rated Fully Tinned, Color Coded Copper Wire
  • Custom In-House Built, Heat Sealed, Mechanically Crimped, Color Coded Battery Cables
  • Custom In-House Built, One-Piece Electrical Harness with Water Proof Connectors and Chafe Protection
  • Powder Coated, Aluminum, Screen Printed (Front and Back) Battery Switch and Breaker Panel
  • Bonding System: Thru Hull Fittings Below Water Line, Trim Tabs, Zinc Anode and Garboard Drain
  • Three Battery System: Port Engine (1), Starboard Engine (1) and House (1)
  • One Grounding Bus Bar
  • Electronics Fuse Block
  • One 12V Outlet (1) and One Dual USB Charger (1)

MECHANICAL SPACE

  • Molded Interior White Gel Coat
  • Molded Hatch with Gasket and Stainless Steel Gas Spring
  • Molded Bilge Sump Area
  • One 1500 GPH Bilge Pump with Electronic Switch, One 1500 GPH Bilge Pump with High Water Electronic Switch and Alarm with Stainless Steel Clad Composite Thru Hull Fittings
  • Fresh Water Pump with Filter
  • Raw Water Pump with Sea Strainer, Sea Cock and Thru Hull Fitting
  • Dedicated Fishbox Diaphragm Evacuation Pumps
  • Livewell Cyclone Pump with Bronze Sea Strainer
  • Teleflex Power Steering Pump

FUEL SYSTEM

  • EPA Compliant Lined Rotomolded 230 Gallon Fuel Tank with Engine Pickups, Shutoff Valves, Digital Level Indicator and Deck Fuel Fill Plate
  • Custom Built Premium Fuel Feed Lines with Mechanically Crimped Fittings
  • Two (2) Yamaha® Water Separating Fuel Filters with Primer Bulbs

WATER SYSTEM

  • 26 Gallon Water Tank and 316L Stainless Steel Deck Fill Plate
  • Premium Sea Tech Color Coded Water Hose System with Mechanically Crimped Ends
  • Pressure Sensing/Variable Speed Pump
  • Centrally Located Freshwater Connections
  • Cockpit Shower



Pursuit reserves the right to change boat specifications, equipment, color schemes, and pricing, and/or discontinue models at any time without notice or obligation. Some of the boats shown include optional or dealer-installed equipment.



COLOR TOOL

Hull Color - Flag Blue

Custom Solid and Effect colors avaiable.

Bootstripe Color - Red/Red

Custom Boot Stripe Color avaiable.

Helm Color - Titanium



OPTIONS

BOAT w/ENGINES

Twin Yamaha® Digital F300 (Pearlescent White) Yamaha Helm Master™ Steering System w/Set Point (Not Available with Bow Thruster)

COLOR SELECTIONS

Hull Color
Titanium (Standard), Neptune Gray, Pursuit Flag Blue, Gulf Stream Blue
Helm Color
Titanium (Standard), Neptune Gray, Pursuit Flag Blue, Gulf Stream Blue
Boot Stripe Color
Black/Black (Standard), Navy/Navy, Platinum/Platinum, Red/Red, Scarlet/Scarlet, Arctic White/Quartz Gray

MECHANICAL SYSTEMS

Bow Thruster (Requires Dockside Power Option) Dockside Power 110v/60Hz LED Mid-Level Accent Lights (4) LED Spotlight w/Remote Control at Helm All Color Sea Blaze Quattro Spectrum Underwater Lights (3) Bow Tow Eye

COMFORT & CONVENIENCE

Fiberglass (Bow/Cockpit) Table w/Dedicated Storage Forward Sunpad with Dedicated Storage Transom Mount Ski Tow

WEATHER

Stowable Cockpit Sunshade Stowable Forward Sunshade Sunbrella® Canvas color - Black, Tweed, Cadet Gray, or Navy Side Curtains - Sunbrella® Side Curtains - Stamoid® (white) Hardtop Aft Curtain, Sunbrella® Hardtop Aft Curtain, Stamoid® - White Bow Tonneau Cover, Stamoid® - White Engine Covers, Sunbrella®

SPORT FISHING

Hardtop Mounted Rod Holders (6) Taco Grand Slam 380 Outriggers w/18' Telescoping Poles

UNDERSIDE HARDTOP COLOR

Titanium Neptune Gray Flag Blue Gulf Stream Blue

ELECTRONICS

Garmin® 7612 Electronics Package
Includes: Garmin® GPSMAP 7612xsv 12" Display, 7612 12" Display, CHIRP B 175M 1kW Thru-Hull Transducer, VHF 300 Marine Radio, VHF Antenna Galaxy 5225XP, Yamaha Gateway, Custom Pursuit Dash Panel
Garmin® GMR™ 24 XHD Dome Garmin® Reactor Corepack w/Smartpump Auto Pilot Garmin® GHP Reactor Auto Pilot (w/Helm Master)
